Ragulated DC power supply PAT-TM/TMX series

PAT-T/TM/TMXシリーズ仕様

PAT-Tシリーズ、PAT-TM/TMXシリーズ別に、製品を一覧表にまとめています。
一覧表から仕様書を開くには、「製品一覧について」を参照してください。



product lineup



product lineup

▲TOP



PAT-Tシリーズ製品一覧



16 kW 24 kW
20V PAT20-200T PAT20-400T
200 V --- 200 V 400 V
30V --- PAT30-266T
    200 V 400 V
40V PAT40-100T PAT40-200T
200 V --- 200 V 400 V
60V PAT60-67T PAT60-133T
200 V --- 200 V 400 V
80V --- PAT80-100T
    200 V 400 V
160V PAT160-25T PAT160-50T
200 V --- 200 V 400 V
250V --- PAT250-32T
    200 V 400 V
350V --- PAT350-22.8T
    200 V 400 V
500V --- PAT500-16T
    200 V 400 V
650V --- PAT650-12.3T
    200 V 400 V
850V --- PAT850-9.4T
    200 V 400 V

▲TOP



PAT-TM/TMXシリーズ製品一覧



16 kW 24 kW 32 kW 40 kW
20V PAT20-800TM/TMX PAT20-1200TM/TMX PAT20-1600TM/TMX PAT20-2000TM/TMX
200 V 400 V 200 V 400 V 200 V 400 V 200 V 400 V
30V PAT30-532TM/TMX PAT30-798TM/TMX PAT30-1064TM/TMX PAT30-1330TM/TMX
200 V 400 V 200 V 400 V 200 V 400 V 200 V 400 V
40V PAT40-400TM/TMX PAT40-600TM/TMX PAT40-800TM/TMX PAT40-1000TM/TMX
200 V 400 V 200 V 400 V 200 V 400 V 200 V 400 V
60V PAT60-266TM/TMX PAT60-399TM/TMX PAT60-532TM/TMX PAT60-665TM/TMX
200 V 400 V 200 V 400 V 200 V 400 V 200 V 400 V
80V PAT80-200TM/TMX PAT80-300TM/TMX PAT80-400TM/TMX PAT80-500TM/TMX
200 V 400 V 200 V 400 V 200 V 400 V 200 V 400 V
160V PAT160-100TM/TMX PAT160-150TM/TMX PAT160-200TM/TMX PAT160-250TM/TMX
200 V 400 V 200 V 400 V 200 V 400 V 200 V 400 V
250V PAT250-64TM/TMX PAT250-96TM/TMX PAT250-128TM/TMX PAT250-160TM/TMX
200 V 400 V 200 V 400 V 200 V 400 V 200 V 400 V
350V PAT350-45.6TM/TMX PAT350-68.4TM/TMX PAT350-91.2TM/TMX PAT350-114TM/TMX
200 V 400 V 200 V 400 V 200 V 400 V 200 V 400 V
500V PAT500-32TM/TMX PAT500-48TM/TMX PAT500-64TM/TMX PAT500-80TM/TMX
200 V 400 V 200 V 400 V 200 V 400 V 200 V 400 V
650V PAT650-24.6TM/TMX PAT650-36.9TM/TMX PAT650-49.2TM/TMX PAT650-61.5TM/TMX
200 V 400 V 200 V 400 V 200 V 400 V 200 V 400 V
850V PAT850-18.8TM/TMX --- --- ---
200 V 400 V
